• MAX 160 mm/s,low noise and high speed printing.
• Supporting printing density adjustment.
• Supporting IAP online upgrade.
• Supports QRcode & PDF417 barcode system.
| Model | |||||
| Printing method | Direct thermal | ||||
| Paper width | 79.5±0.5mm | ||||
| Print width | 72mm | ||||
| Column capacity | 576 dots/line | ||||
| Printing speed | 160 mm/s | ||||
| Interface | USB+SeriaI+Parallel | ||||
| Line spacing | 3.75mm | ||||
| Character size | ANK,Font A:1.5×3.0mm (12×24 dots) Font B:1.1×2.1mm (9×17 dots) Chinese:3.0×3.0mm (24×24 dots) | ||||
| Barcode Character | |||||
| Extension character sheet | PC347(Standard Europe)/Katakana/PC850(Multilingual)/PC860(Portuguese)/PC863(Canadian-French)/PC865(Nordic)/West Europe/Greek /Hebrew/East Europe/Iran/WPC1252/PC866(Cyrillic#2)/PC852(Latin2)/Pc858/IranIl/Latvian /Arabic/PT151(1251) | ||||
| Barcode types | UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128 | ||||
| 2D Barcode | QR CODE / PDF417 | ||||
| Input buffer | 32Kbytes | ||||
| NV FIash | 64Kbytes | ||||
| Power | |||||
| Power source input | DC 24V / 2.5A | ||||
| Cash drawer output | DC 12V / 1A | ||||
| Physical characteristics | |||||
| Weight | 0.37 KG | ||||
| Dimensions | 140x142x110.7mm(D*W*H) | ||||
| Environmental Requirements | |||||
| Work environment | Temperature: 0~45°C humidity:RH10~80% | ||||
| Storage environment | Temperature: -10~60°C humidity:RH10~90C | ||||
| Reliability | |||||
| Cutter life | 1 million cuts | ||||
| Printer head life | 100 KM | ||||
